SMART BLINKY REMOTE™ BATTERY WATERING MONITOR
The SmartBlinky Remote is an electrolyte level indicator designed for lead-acid batteries that do not leave the forklift trucks or for industrial batteries that are charged on multi-level racks.
Perfect for these applications |
Forklift
Scrubbers
Aerial Access
Buggies
Marine
Part no. | ACC-SREM3
Cost Effective
Over a battery's lifetime, the SmartBlinky Remote saves a surprising amount of time or labour cost and delivers a rapid return on investment. The cost of a single SmartBlinky Remote is a minimal addition to the purchase price of an industrial battery. Still, it allows watering on a labour-saving 'when-needed' basis instead of a 'hit or miss schedule'. This is even more important with batteries that require less frequent water additions.
Simple LED Feedback
The SmartBlinky Remote monitor makes battery watering simple and reliable. It blinks green when electrolyte levels are correct and turns red when water is needed, even visible from across a dark battery room. This saves operators time by showing exactly which batteries require attention, while preventing unnecessary checks and costly overfilling. With SmartBlinky Remote, you’ll always know when to water and when to leave your batteries alone.
Engineered to be Tough
The SmartBlinky Remote battery watering monitor is built to withstand the harsh environment of industrial battery applications. All materials are resistant to corrosion, and the low-profile design protects against damage from battery cables and other hazards. It is designed to last for the life of the battery.
Patented Smart Sensing Technology
The SmartBlinky Remote monitor has a patented Smart Delay Technology that eliminates false indications and prevents unnecessary watering.
Why Smart Blinky Remote
The SmartBlinky Remote is a mid-range electrolyte indicator that can be edge-mounted for batteries where the top is inaccessible.
Immediate ROI
SmartBlinky Remote is a low-cost solution that quickly pays for itself through reduced labour and maintenance costs.
Patented Design
SmartBlinky Remote is an electronic probe that senses the electrolyte in a cell. The simple, low-cost circuit provides a clear indication when the battery needs water.
Wide Operating Range
Works on all industrial lead acid batteries from 4 to 12 volts, including 6 and 12-volt golf and block batteries.
Edge-Mounted
The SmartBlinky Remote can be edge-mounted on a battery for higher visibility.
Super Bright LED Indicators
A bright flashing green LED means the electrolyte level is OK, while a bright red flashing light means it is time to water the cells.
Easy to Install
A quick and simple installation procedure with reverse polarity protection, and multiple connection types available.
Technical Specifications
|
LED Indications |
Green Flash: Electrolyte Level OK Red Flash: Fill Soon |
|
System Exposure Temperature |
-29° to 71°C / -20° to 160°F |
|
Operating Voltage |
4.0 to 12.0 VDC, 6.0 VDC Nominal |
|
Forgiveness Zone |
14.0 to 16.0 VDC |
|
Permanent Failure |
18.0 VDC or greater |
|
Nominal Current |
24mA |
|
6V & 12V Monobloc |
Yes |
|
Any Cell Installation |
No |
|
Reverse Polarity Protection |
Yes |
|
Fuses |
FlexiTap (Q): 2 x Board, 1 x In-connector M4 Screw (S): 2 x Board M10 Bolt (B): 2 x Board |
|
Connection Types |
FlexiTap (Q), M4 Screw (S), M10 Bolt (B) |
|
Flame Retardant |
UL V-0 |
|
Certification |
UL, C-Tick, CE Mark |
|
Weight |
58.1g / 2.05oz |
|
Housing Dimensions |
41mm (L) x 31mm (W) x 10mm (H) / 1.61in (L) x 1.22in (W) x 0.39in (H) |
|
Generation |
Second |
|
Warranty |
1 Years |
|
ROI |
20 Weeks |
Resources
FAQs
The SmartBlinky Remote has a solid green light with no flashing. What does this mean?
A solid green LED on the Blinky is potentially indicating that the circuit has failed. We would suggest contacting your local Philadelphia Scientific distributor for further investigation.
The Blinky is flashing red, then when I take it out, it doesn't flash at all. Why is this happening?
The most likely cause of this would be that the negative fuse has ruptured and once replaced should work, if you need any further information we would suggest contacting your local Philadelphia Scientific distributor.
