HydroPure™ Deionizer System

Maximise battery performance with pure water from the tap.

Perfect for these applications  |

Forklift   Scrubbers   Aerial Access   Buggies   Marine

Part no.  |  PS-300

Ease of Operation

This system comes with everything needed to produce pure water straight from the tap. It operates at full-line pressure, dispensing purified water directly from the deionizer. The cartridges can be replaced quickly without the need for tools, and the included 20ft output hose provides maximum flexibility and convenience for watering.

High Capacity

The amount of purified water produced by the HydroPure cartridge will average about 600 gallons, but this will vary with the quality of the incoming tap water, from as much as 1,500 gallons to as little as 250.

Exclusive Purity Light Indicator

The dual-colour light indicator signals when it’s time to change the cartridge, and no light means the batteries of the purity light should be changed. The system comes with two D-cell batteries that last up to two years, eliminating the need for an AC power source. This design keeps electricity and water separate, ensuring greater safety for employees.

Why HydroPure Deionizer

Professional quality deionizers: Not just a filter, which only removes particles, but a real ion-exchange medium which electrostatically removes dissolved impurities. Purity is comparable to distilled water and ideal for batteries.

Ease of Installation

A mounting plate with hose hanger allows easy installation, and the cartridge connects in seconds using standard hose fittings and quick-connect couplings. No plumber is needed, and replacement is simple with non-toxic, easily disposable cartridges.

Pressurized System

Unlike some lab-type systems, the HydroPure Cartridge takes full-line pressure up to 80psi. So the water flow is fast enough to use directly with the Battery Watering Gun.

Low Cost

Cartridges are available for a fraction of the cost of distilled water, enabling battery users to produce their own pure water for less money than it would cost to buy it.

High Capacity

A single cartridge will produce an average of 600 gallons of purified water. The amount will vary with the quality of the incoming tap water, from as much as 1,500 gallons to as little as 250. Most battery manufacturers recommend that water should have no more than 50 parts per million total dissolved solids to get full battery life.

Watering Gun Available

An optional battery watering gun is available, enabling a battery to be filled directly from the deionizer.

Purity Chart

The following chart can be used to determine how many gallons of pure battery water
can be obtained from one cartridge based on the purity of the incoming tap water.

Purity Level

Total Dissolved Solids**

Cartridge Capacity

Good

PPM*

50

75

Grains

3

4

uS/cm

28

42

U.S. Gallons

1440

960

Liters

5,451

3,634

Average

PPM*

100

120

150

Grains

6

7

9

uS/cm

56

67

84

U.S. Gallons

720

600

480

Liters

2,725

2,271

1,817

Poor

PPM*

200

250

Grains

12

15

uS/cm

112

140

U.S. Gallons

360

288

Liters

1,363

1,090

**TDS: Total Dissolved Solids in the water
*PPM: Parts per million is equal to mg/liter of water

Technical Specifications

Input / Operating Pressure

< 80 psi  /  < 5.52 bar

Flow Rate

0.5 gpm with the provided restrictor  / 1.89 lpm

System Exposure Temperature

35° to 160°F  /  2° to 71°C

Power Source

Purity Light: 2 D-Cell Batteries (included)
Battery Life Estimate: 2 Years

Purity Light Setting

50 ppm total dissolved solids

Input Hose Size

3/8 in  /  1.3 cm

Input Hose Length

10 ft  /  3.0 m

Output Hose Size

3/8 in  /  1.3 cm

Output Hose Length

20 ft  /  6.0 m

Weight

24 lb  /  10.8 kg

Product Height

44 in  /  111.7 cm

Product Length

7 in  /  17.8 cm

Product Width

6 in  /  15.2 cm

Capacity

600 gallons  /  2270 litres
*Based on incoming water quality

Compatible With

HydroFill Pro Watering Cart

Water Injector Systems

Stealth Watering System

Watering Gun-X

FAQs

I have installed the HydroPure Deionizer, but the purity light is flashing red. Why is this?

Before first use, run 10 gallons / 40 litres of water and check again.

If you are using the deionizer to fill a watering cart or a bucket, be sure to have the flow restrictor connected to the end of the output hose. The water needs enough time to interact with the resins inside the cartridge to deionise effectively.

If the problem persists, remove the purity light from the deionizer and leave it to dry in open air for 30 minutes. If the light is still flashing red in the open air, you will need to replace the purity light.

If the purity light flashes green in the open air and then flashes red when reattached to the cartridge, please get in touch with customer service to help diagnose the issue.



How much water can I expect out of one cartridge?

The capacity of the cartridge is directly related to the purity of the incoming water, or TDS level. To determine what the capacity will be precisely, you must test the incoming water with a TDS meter. Using the Cartridge Output Calculator at the bottom of the page, enter the resulting Parts Per Million data to see how many gallons/litres you will get from your cartridges.



Can I connect the Deionizer to a Water Injector System?

No, the Injector system requires consistent 25-35 PSI to function correctly, which the deionizer cannot produce.



What is the shelf life of the cartridge?

The deionizer cartridge has a shelf life of 5 years.



How long can I extend the length of the output hose?

If connecting to a Stealth system, the maximum length is 100 ft.

If connecting to a Watering Gun (GUN-X, GUN-S, GUN-RR), you must confirm that your flowing water pressure is at least 30 PSI, which will allow you to extend the output hose up to 100 ft.
